133 Mhz and 64 MB. Package including:
- PM866A, CPU
- TP830, Baseplate, width =115mm
- TB850, CEX-bus terminator
- TB807, ModuleBus terminator
- TB852, RCU-Link terminator
- Battery for memory backup (4943013-6)
- No license included

PM866AK02
133 Mhz and 64 MB. Package including:
- 2 pcs PM866A, CPU
- 2 pcs TP830, Baseplate, width =115mm
- 2 pcs TB807, ModuleBus terminator
- 1 pcs TK850, CEX-bus expansion cable
- 1 pcs TB851, RCU-Link cable
- 2 pcs Battery for memory backup (4943013-6)
- No license included

450 Mhz and 256 MB. Package including:
- PM891 CPU Module
- TB850, CEX-bus terminator
- TB853, RCU Control Link Terminator
- No license included

450 Mhz and 256 MB. Package including:
- 2 pcs PM891K01 Processor Unit
- 1 pcs TK850V007 CEX-bus Extension Cable
- 1 pcs TK855 RCU Data Link Cable
- 1 pcs TK856 RCU Control Link Cable
- No license included

The AC 800F modules are supplied with 5 VDC / 5.5 A and 3.3 VDC / 6.5 A by SA 811F. The power supply has open-circuit, overload and sustained short-circuit protection. The electronically controlled output voltage provides high stability and
low residual ripple.

SA 811F-Z, Power Supply 115/230 Vac

The power supply filter type BP901S is not required.
SA920B is the functional replacement for SA910B
Do not mix SA910B with SA920B for redundancy.

The power supply filter type BP901S is not required.
SA920N is the functional replacement for SA910N
Do not mix SA910N with SA920N for redundancy.

24VDC Power Supply, ABB

SB822, External DIN-rail mounted rechargeable battery unit

SD 812F, Power Supply, Input voltage 24Vdc, Output voltage 5Vdc

SD 812F-Z, Power Supply 24Vdc

TA 724F, Dummy Coupler Module, cover for unused slots

TA 924F, Dummy Coupler Module, cover for unused slots

AC500 TA5131-RTC REALTIME Clock Option Board AC500 eCo Version 3 PLC Accessory

TA521, Battery for RAM buffering, Button Cell, Lithium, For PM 783F

TA5211, Terminal Blocks, 1-3 Pole and 1-13 Pole, Screw type connection

F110 - TB 711F, CPU Terminal Base24 VDC, 1x Fieldbus slot, Ethernet RJ45For PM 783F

TB 870F, Terminal Block for serial interface

TB807 Modulebus Terminator

TB850 CEX-Bus Terminator
With 25-pin DB25P male connector. With screw fixing.
A TB850 CEX-Bus terminator must always be installed on the
last unit on the CEX bus.

TB851 CEX-Bus Terminator
With 25-pin DB25S female connector. With screw fixing.
When Communication Interface units are mounted on
adjacent DIN rails, they are connected by means of a CEX-Bus
extension cable (TK850) and terminated using a TB851
CEX-Bus terminator.

TB852, RCU Link Terminator

TB853, RCU Control Link Terminator

TC505A Kabel, Cable, Pref. cable
