Type 4

 Select Sub Categories Below

Sort By Sort By: Featured
[NE08048604] Thermal Edge Panel Mount AC Unit BTU/H: 8000 Type 4 - Volts - 460/1/60

Thermal Edge Panel Mount AC Unit BTU/H: 8000 Type 4 - Volts - 460/1/60

BTU/H: 8000 Material: Powder Coated Steel Volt./Hz.: 460/1/60 Running Amps: 2.4 Max. Ambient Temperature: 125°F H X W x D: 44.63" x 11.8" x 15.02" Unit Weight (lbs): 142 Shipping Weight (lbs): 156
[NE08023604] Thermal Edge Panel Mount AC Unit BTU/H: 8000 Type 4 - Volts - 230/1/60

Thermal Edge Panel Mount AC Unit BTU/H: 8000 Type 4 - Volts - 230/1/60

BTU/H: 8000 Material: Powder Coated Steel Volt./Hz.: 230/1/60 Running Amps: 4.8 Max. Ambient Temperature: 125°F H X W x D: 36" x 11.8" x 15.02" Unit Weight (lbs): 98 Shipping Weight (lbs): 112
[NE08012604] Thermal Edge Panel Mount AC Unit BTU/H: 8000 Type 4 - Volts - 115/1/60

Thermal Edge Panel Mount AC Unit BTU/H: 8000 Type 4 - Volts - 115/1/60

BTU/H: 8000 Material: Powder Coated Steel Volt./Hz.: 115/1/60 Running Amps: 7.83 Max. Ambient Temperature: 125°F H X W x D: 36" x 11.8" x 15.02" Unit Weight (lbs): 97 Shipping Weight (lbs): 111
[NE06048604] Thermal Edge Panel Mount AC Unit BTU/H: 6000 Type 4 - Volts - 460/1/60

Thermal Edge Panel Mount AC Unit BTU/H: 6000 Type 4 - Volts - 460/1/60

BTU/H: 6000 Material: Powder Coated Steel Volt./Hz.: 460/1/60 Running Amps: 2.4 Max. Ambient Temperature: 125°F H X W x D: 44.63" x 11.8" x 15.02" Unit Weight (lbs): 142 Shipping Weight (lbs): 156
[NE06023604] Thermal Edge Panel Mount AC Unit BTU/H: 6000 Type 4 - Volts - 230/1/60

Thermal Edge Panel Mount AC Unit BTU/H: 6000 Type 4 - Volts - 230/1/60

BTU/H: 6000 Material: Powder Coated Steel Volt./Hz.: 230/1/60 Running Amps: 4.8 Max. Ambient Temperature: 125°F H X W x D: 36" x 11.8" x 15.02" Unit Weight (lbs): 98 Shipping Weight (lbs): 112
[NE06012604] Thermal Edge Panel Mount AC Unit BTU/H: 6000 Type 4 - Volts - 115/1/60

Thermal Edge Panel Mount AC Unit BTU/H: 6000 Type 4 - Volts - 115/1/60

BTU/H: 6000 Material: Powder Coated Steel Volt./Hz.: 115/1/60 Running Amps: 7.83 Max. Ambient Temperature: 125°F H X W x D: 36" x 11.8" x 15.02" Unit Weight (lbs): 97 Shipping Weight (lbs): 111
[NE05048604] Thermal Edge Panel Mount AC Unit BTU/H: 5000 Type 4 - Volts - 460/1/60

Thermal Edge Panel Mount AC Unit BTU/H: 5000 Type 4 - Volts - 460/1/60

BTU/H: 5000 Material: Powder Coated Steel Volt./Hz.: 460/1/60 Running Amps: 1.9 Max. Ambient Temperature: 125°F H X W x D: 44.63" x 11.8" x 15.02" Unit Weight (lbs): 136 Shipping Weight (lbs): 150
[NE05023604] Thermal Edge Panel Mount AC Unit BTU/H: 5000 Type 4 - Volts - 230/1/60

Thermal Edge Panel Mount AC Unit BTU/H: 5000 Type 4 - Volts - 230/1/60

BTU/H: 5000 Material: Powder Coated Steel Volt./Hz.: 230/1/60 Running Amps: 3.76 Max. Ambient Temperature: 125°F H X W x D: 36" x 11.8" x 15.02" Unit Weight (lbs): 92 Shipping Weight (lbs): 106
[NE05012604] Thermal Edge Panel Mount AC Unit BTU/H: 5000 Type 4 - Volts - 115/1/60

Thermal Edge Panel Mount AC Unit BTU/H: 5000 Type 4 - Volts - 115/1/60

BTU/H: 5000 Material: Powder Coated Steel Volt./Hz.: 115/1/60 Running Amps: 7.26 Max. Ambient Temperature: 125°F H X W x D: 36" x 11.8" x 15.02" Unit Weight (lbs): 97 Shipping Weight (lbs): 111
[NE04048604] Thermal Edge Panel Mount AC Unit BTU/H: 4000 Type 4 - Volts - 460/1/60

Thermal Edge Panel Mount AC Unit BTU/H: 4000 Type 4 - Volts - 460/1/60

BTU/H: 4000 Material: Powder Coated Steel Volt./Hz.: 460/1/60 Running Amps: 1.3 Max. Ambient Temperature: 125°F H X W x D: 38" x 11.8" x 9.5" Unit Weight (lbs): 99 Shipping Weight (lbs): 113
[NE04023604] Thermal Edge Panel Mount AC Unit BTU/H: 4000 Type 4 - Volts - 230/1/60

Thermal Edge Panel Mount AC Unit BTU/H: 4000 Type 4 - Volts - 230/1/60

BTU/H: 4000 Material: Powder Coated Steel Volt./Hz.: 230/1/60 Running Amps: 3.07 Max. Ambient Temperature: 125°F H X W x D: 32" x 11.8" x 9.5" Unit Weight (lbs): 72 Shipping Weight (lbs): 86
[NE04012604] Thermal Edge Panel Mount AC Unit BTU/H: 4000 Type 4 - Volts - 115/1/60

Thermal Edge Panel Mount AC Unit BTU/H: 4000 Type 4 - Volts - 115/1/60

BTU/H: 4000 Material: Powder Coated Steel Volt./Hz.: 115/1/60 Running Amps: 5.15 Max. Ambient Temperature: 125°F H X W x D: 32" x 11.8" x 9.5" Unit Weight (lbs): 66 Shipping Weight (lbs): 80
[NE03023604] Thermal Edge Panel Mount AC Unit BTU/H: 3000 Type 4 - Volts - 230/1/60

Thermal Edge Panel Mount AC Unit BTU/H: 3000 Type 4 - Volts - 230/1/60

BTU/H: 3000 Material: Powder Coated Steel Volt./Hz.: 230/1/60 Running Amps: 3.07 Max. Ambient Temperature: 125°F H X W x D: 32" x 11.8" x 9.5" Unit Weight (lbs): 72 Shipping Weight (lbs): 86
[NE03012604] Thermal Edge Panel Mount AC Unit BTU/H: 3000 Type 4 - Volts - 115/1/60

Thermal Edge Panel Mount AC Unit BTU/H: 3000 Type 4 - Volts - 115/1/60

BTU/H: 3000 Material: Powder Coated Steel Volt./Hz.: 115/1/60 Running Amps: 5.15 Max. Ambient Temperature: 125°F H X W x D: 32" x 11.8" x 9.5" Unit Weight (lbs): 66 Shipping Weight (lbs): 80
[NE02048604] Thermal Edge Panel Mount AC Unit BTU/H: 2000 Type 4 - Volts - 460/1/60

Thermal Edge Panel Mount AC Unit BTU/H: 2000 Type 4 - Volts - 460/1/60

BTU/H: 2000 Material: Powder Coated Steel Volt./Hz.: 460/1/60 Running Amps: 0.94 Max. Ambient Temperature: 125°F H X W x D: 38" x 11.8" x 9.5" Unit Weight (lbs): 99 Shipping Weight (lbs): 113
[NE02023604] Thermal Edge Panel Mount AC Unit BTU/H: 2000 Type 4 - Volts - 230/1/60

Thermal Edge Panel Mount AC Unit BTU/H: 2000 Type 4 - Volts - 230/1/60

BTU/H: 2000 Material: Powder Coated Steel Volt./Hz.: 230/1/60 Running Amps: 3.07 Max. Ambient Temperature: 125°F H X W x D: 32" x 11.8" x 9.5" Unit Weight (lbs): 72 Shipping Weight (lbs): 86
[NE02012604] Thermal Edge Panel Mount AC Unit BTU/H: 2000 Type 4 - Volts - 115/1/60

Thermal Edge Panel Mount AC Unit BTU/H: 2000 Type 4 - Volts - 115/1/60

BTU/H: 2000 Material: Powder Coated Steel Volt./Hz.: 115/1/60 Running Amps: 3.76 Max. Ambient Temperature: 125°F H X W x D: 32" x 11.8" x 9.5" Unit Weight (lbs): 65 Shipping Weight (lbs): 79
[NE01523604] Thermal Edge Panel Mount AC Unit BTU/H: 1500 Type 4 - Volts - 230/1/60

Thermal Edge Panel Mount AC Unit BTU/H: 1500 Type 4 - Volts - 230/1/60

BTU/H: 1500 Material: Powder Coated Steel Volt./Hz.: 230/1/60 Running Amps: 2.67 Max. Ambient Temperature: 125°FH X W x D: 22" x 11.8" x 8.5"Unit Weight (lbs): 53 Shipping Weight (lbs): 67
[NE01512604] Thermal Edge Panel Mount AC Unit BTU/H: 1500 Type 4 - Volts - 115/1/60

Thermal Edge Panel Mount AC Unit BTU/H: 1500 Type 4 - Volts - 115/1/60

BTU/H: 1500 Material: Powder Coated Steel Volt./Hz.: 115/1/60 Running Amps: 3.44 Max. Ambient Temperature: 125°FH X W x D: 22" x 11.8" x 8.5"Unit Weight (lbs): 51 Shipping Weight (lbs): 65
[NE01012604] Thermal Edge Panel Mount AC Unit BTU/H: 1000 Type 4 - Volts - 115/1/60

Thermal Edge Panel Mount AC Unit BTU/H: 1000 Type 4 - Volts - 115/1/60

BTU/H: 1000 Material: Powder Coated Steel Volt./Hz.: 115/1/60 Running Amps: 3.44 Max. Ambient Temperature: 125°FH X W x D: 22" x 11.8" x 8.5"Unit Weight (lbs): 51 Shipping Weight (lbs): 65
[HC20148604] Thermal Edge Panel Mount AC Unit BTU/H: 20,000 Type 4 - Volts - 460/1/60

Thermal Edge Panel Mount AC Unit BTU/H: 20,000 Type 4 - Volts - 460/1/60

BTU/H: 20,000 Material: Powder Coated Steel Volt./Hz.: 460/1/60 Running Amps: 6.9 Max. Ambient Temperature: 131°F H X W x D: 65.7" x 23" x 15.03" Unit Weight (lbs): 337 Shipping Weight (lbs): 380
[HC20123604] Thermal Edge Panel Mount AC Unit BTU/H: 20,000 Type 4 - Volts - 230/1/60

Thermal Edge Panel Mount AC Unit BTU/H: 20,000 Type 4 - Volts - 230/1/60

BTU/H: 20,000 Material: Powder Coated Steel Volt./Hz.: 230/1/60 Running Amps: 13.7 Max. Ambient Temperature: 131°F H X W x D: 56.09" x 23" x 15.03" Unit Weight (lbs): 205 Shipping Weight (lbs): 225
[HC15148604] Thermal Edge Panel Mount AC Unit BTU/H: 15,000 Type 4 - Volts - 460/1/60

Thermal Edge Panel Mount AC Unit BTU/H: 15,000 Type 4 - Volts - 460/1/60

BTU/H: 15,000 Material: Powder Coated Steel Volt./Hz.: 460/1/60 Running Amps: 5.7 Max. Ambient Temperature: 131°F H X W x D: 56.6" x 15.86" x 15.03" Unit Weight (lbs): 247 Shipping Weight (lbs): 290
[HC15123604] Thermal Edge Panel Mount AC Unit BTU/H: 15,000 Type 4 - Volts - 230/1/60

Thermal Edge Panel Mount AC Unit BTU/H: 15,000 Type 4 - Volts - 230/1/60

BTU/H: 15,000 Material: Powder Coated Steel Volt./Hz.: 230/1/60 Running Amps: 11.3 Max. Ambient Temperature: 131°F H X W x D: 48" x 15.86" x 15.03" Unit Weight (lbs): 170 Shipping Weight (lbs): 190
[HC12148604] Thermal Edge Panel Mount AC Unit BTU/H: 12,000 Type 4 - Volts - 460/1/60

Thermal Edge Panel Mount AC Unit BTU/H: 12,000 Type 4 - Volts - 460/1/60

BTU/H: 12,000 Material: Powder Coated Steel Volt./Hz.: 460/1/60 Running Amps: 4.1 Max. Ambient Temperature: 131°FH X W x D: 56.6" x 15.86" x 15.03" Unit Weight (lbs): 237 Shipping Weight (lbs): 280
